Bouffalo Lab BL702 - Software Reset Function Table

BL702/704/706 Reference Manual
Table 3.1: Software reset function table
BL702 RST_PIN/HBN/WDT
/POWER ON
SW.Reset CPU/PDS/SYS PDS/CPU PDS
CPU ✓
✓
✓ ✓
✓
✓
bus ✓
✓
✓ ✓
✓
✓
glb ✓
✓
✓ swrst_s1[0]
gpip ✓
✓
✓ swrst_s1[2] ✓
✓
✓
l1c ✓
✓
✓ swrst_s1[9] ✓
✓
✓ ✓
✓
✓
dma ✓
✓
✓ swrst_s1[12] ✓
✓
✓
emac ✓
✓
✓ swrst_s1[13] ✓
✓
✓
usb ✓
✓
✓ swrst_s1a[12] ✓
✓
✓ ✓
✓
✓
pds swrst_s1[14]
uart0 ✓
✓
✓ swrst_s1a[0] ✓
✓
✓
uart1 ✓
✓
✓ swrst_s1a[1] ✓
✓
✓
spi ✓
✓
✓ swrst_s1a[2] ✓
✓
✓
I2C ✓
✓
✓ swrst_s1a[3] ✓
✓
✓
pwm ✓
✓
✓ swrst_s1a[4] ✓
✓
✓
timer ✓
✓
✓ swrst_s1a[5] ✓
✓
✓
irr ✓
✓
✓ swrst_s1a[6] ✓
✓
✓
qdec0 ✓
✓
✓ swrst_s1a[8] ✓
✓
✓
qdec1 ✓
✓
✓ swrst_s1a[8] ✓
✓
✓
qdec2 ✓
✓
✓ swrst_s1a[8] ✓
✓
✓
kys ✓
✓
✓ swrst_s1a[9] ✓
✓
✓
i2s ✓
✓
✓ swrst_s1a[10] ✓
✓
✓
