BL702/704/706 Reference Manual
3.3.21 GPIO_CFGCTL3
Address：0x4000010c
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD GP7FUNC RSVD GP7
PD
GP7
PU
GP7DRV GP7
SMT
GP7
IE
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RSVD GP6FUNC RSVD GP6
PD
GP6
PU
GP6DRV GP6
SMT
GP6
IE
Bits
Name Type Reset Description
31:29 RSVD
28:24 GP7FUNC R/W 5’hB GPIO Function Select (Default : SWGPIO)
23:22 RSVD
21 GP7PD R/W 0 GPIO Pull Down Control
20 GP7PU R/W 0 GPIO Pull Up Control
19:18 GP7DRV R/W 0 GPIO Driving Control
17 GP7SMT R/W 1 GPIO SMT Control
16 GP7IE R/W 1 GPIO Input Enable
15:13 RSVD
12:8 GP6FUNC R/W 5’hB GPIO Function Select (Default : SWGPIO )
7:6 RSVD
5 GP6PD R/W 0 GPIO Pull Down Control
4 GP6PU R/W 0 GPIO Pull Up Control
3:2 GP6DRV R/W 0 GPIO Driving Control
1 GP6SMT R/W 1 GPIO SMT Control
0 GP6IE R/W 1 GPIO Input Enable
BL702/704/706 Reference Manual 56/ 375
