BL702/704/706 Reference Manual
12.4.15 pwm2_thre1
Address：0x4000a464
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
THRE1
Bits
Name Type Reset Description
31:16 RSVD
15:0 THRE1 R/W 16’b0 PWM first counter threshold, can’t be larger that pwm_thre2
12.4.16 pwm2_thre2
Address：0x4000a468
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
THRE2
Bits
Name Type Reset Description
31:16 RSVD
15:0 THRE2 R/W 16’d0 PWM sencond counter threshold, can’t be smaller that
pwm_thre1
12.4.17 pwm2_period
Address：0x4000a46c
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
PERIOD
Bits
Name Type Reset Description
31:16 RSVD
