BL702/704/706 Reference Manual
13.4.28 TILR3
Address：0x4000a594
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RSVD TILR
32
TILR
31
TILR
30
Bits
Name Type Reset Description
31:3 RSVD
2 TILR32 R/W 1’b0 Timer3 match 0/1/2 interrupt mode register
1’b0 - level interrupt
1’b1 - pulse interrupt
1 TILR31 R/W 1’b0 Timer3 match 0/1/2 interrupt mode register
1’b0 - level interrupt
1’b1 - pulse interrupt
0 TILR30 R/W 1’b0 Timer3 match 0/1/2 interrupt mode register
1’b0 - level interrupt
1’b1 - pulse interrupt
13.4.29 WCR
Address：0x4000a598
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RSVD WCR
Bits
Name Type Reset Description
31:1 RSVD
0 WCR W 1’b0 WDT timer count reset register
