BL702/704/706 Reference Manual
Bits
Name Type Reset Description
31:2 RSVD
1 MIIMBUSY R 1’b0 MIIM I/F busy signal
0: The MIIM I/F is ready.
1: The MIIM I/F is busy.
0 MIIMLF R 1’b0 MIIM I/F link fail signal
17.8.14 MAC_ADDR0
Address：0x4000d040
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
MACB2 MACB3
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
MACB4 MACB5
Bits
Name Type Reset Description
31:24 MACB2 R/W 8’d0 Ethernet MAC address byte 2
23:16 MACB3 R/W 8’d0 Ethernet MAC address byte 3
15:8 MACB4 R/W 8’d0 Ethernet MAC address byte 4
7:0 MACB5 R/W 8’d0 Ethernet MAC address byte 5
17.8.15 MAC_ADDR1
Address：0x4000d044
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
MACB0 MACB1
Bits
Name Type Reset Description
31:16 RSVD
15:8 MACB0 R/W 8’d0 Ethernet MAC address byte 0
7:0 MACB1 R/W 8’d0 Ethernet MAC address byte 1
