BL702/704/706 Reference Manual
18.4.21 ep1_fifo_config
Address：0x4000d910
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RSVD E1
RFU
E1
RFO
E1
TFU
E1
TFO
E1
RFC
E1
TFC
E1
DREN
E1
DTEN
Bits
Name Type Reset Description
31:8 RSVD
7 E1RFU R 1’b0 Underflow flag of RX FIFO, can be cleared by rx_fifo_clr
6 E1RFO R 1’b0 Overflow flag of RX FIFO, can be cleared by rx_fifo_clr
5 E1TFU R 1’b0 Underflow flag of TX FIFO, can be cleared by tx_fifo_clr
4 E1TFO R 1’b0 Overflow flag of TX FIFO, can be cleared by tx_fifo_clr
3 E1RFC W1C 1’b0 Clear signal of RX FIFO
2 E1TFC W1C 1’b0 Clear signal of TX FIFO
1 E1DREN R/W 1’b0 Enable signal of dma_rx_req/ack interface
Set 1 when use DMA for rx FIFO data transfer
0 E1DTEN R/W 1’b0 Enable signal of dma_tx_req/ack interface
Set 1 when use DMA for tx FIFO data transfer
18.4.22 ep1_fifo_status
Address：0x4000d914
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
E1
RFF
E1
RFE
RSVD E1RFC
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
E1
TFF
E1
TFE
RSVD E1TFC
Bits
Name Type Reset Description
31 E1RFF R 1’b0 RX FIFO full flag
30 E1RFE R 1’b1 RX FIFO empty flag
29:23 RSVD
BL702/704/706 Reference Manual 335/ 375
