BL702/704/706 Reference Manual

18.4.41 ep6_fifo_config

Address：0x4000d960

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

RSVD

15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

RSVD E6

RFU

RFO

TFU

TFO

RFC

TFC

DREN

DTEN

Bits

Name Type Reset Description

31:8 RSVD

7 E6RFU R 1’b0 Underflow flag of RX FIFO, can be cleared by rx_fifo_clr

6 E6RFO R 1’b0 Overflow flag of RX FIFO, can be cleared by rx_fifo_clr

5 E6TFU R 1’b0 Underflow flag of TX FIFO, can be cleared by tx_fifo_clr

4 E6TFO R 1’b0 Overflow flag of TX FIFO, can be cleared by tx_fifo_clr

3 E6RFC W1C 1’b0 Clear signal of RX FIFO

2 E6TFC W1C 1’b0 Clear signal of TX FIFO

1 E6DREN R/W 1’b0 Enable signal of dma_rx_req/ack interface

Set 1 when use DMA for rx FIFO data transfer

0 E6DTEN R/W 1’b0 Enable signal of dma_tx_req/ack interface

Set 1 when use DMA for tx FIFO data transfer

18.4.42 ep6_fifo_status

Address：0x4000d964

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

RFF

RFE

RSVD E6RFC

15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

TFF

TFE

RSVD E6TFC

Bits

Name Type Reset Description

31 E6RFF R 1’b0 RX FIFO full flag

30 E6RFE R 1’b1 RX FIFO empty flag

29:23 RSVD

BL702/704/706 Reference Manual 345/ 375
