BL702/704/706 Reference Manual
Bits
Name Type Reset Description
31:30 RSVD
29:0 GPITMS2 R/W 0 [2:0] : GPIO 10 Interrupt Mode Control[2:0]
[5:3] : GPIO 11 Interrupt Mode Control[2:0]
[8:6] : GPIO 12 Interrupt Mode Control[2:0]
[11:9] : GPIO 13 Interrupt Mode Control[2:0]
[14:12] : GPIO 14 Interrupt Mode Control[2:0]
[17:15] : GPIO 15 Interrupt Mode Control[2:0]
[20:18] : GPIO 16 Interrupt Mode Control[2:0]
[23:21] : GPIO 17 Interrupt Mode Control[2:0]
[26:24] : GPIO 18 Interrupt Mode Control[2:0]
[29:27] : GPIO 19 Interrupt Mode Control[2:0]
GPIO X Interrupt Mode Control [2:0]
[2] :
1 : async mode
0 : sync mode
[1:0] :
00 : negedge pulse
01 : posedge pulse
10 : negedge level (32k 3T)
11 : posedge level (32k 3T)
3.3.46 GPIO_INT_MODE_SET3
Address：0x400001c8
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD GPITMS3
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
GPITMS3
Bits
Name Type Reset Description
31:30 RSVD
