BL702/704/706 Reference Manual
Bits
Name Type Reset Description
29:0 GPIT2MS1 R/W 0 [2:0] : GPIO 0 Interrupt Mode Control[2:0]
[5:3] : GPIO 1 Interrupt Mode Control[2:0]
[8:6] : GPIO 2 Interrupt Mode Control[2:0]
[11:9] : GPIO 3 Interrupt Mode Control[2:0]
[14:12] : GPIO 4 Interrupt Mode Control[2:0]
[17:15] : GPIO 5 Interrupt Mode Control[2:0]
[20:18] : GPIO 6 Interrupt Mode Control[2:0]
[23:21] : GPIO 7 Interrupt Mode Control[2:0]
[26:24] : GPIO 8 Interrupt Mode Control[2:0]
[29:27] : GPIO 9 Interrupt Mode Control[2:0]
GPIO X Interrupt Mode Control [2:0]
[2] :
1 : async mode
0 : sync mode
[1:0] :
00 : negedge pulse
01 : posedge pulse
10 : negedge level (32k 3T)
11 : posedge level (32k 3T)
3.3.52 GPIO_INT2_MODE_SET2
Address：0x400001e0
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD GPIT2MS2
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
GPIT2MS2
Bits
Name Type Reset Description
31:30 RSVD
