Braun Aesculap ELAN 4 User Manual

2
Aesculap
®
ELAN 4 air motor hose 3 m with hand control GA706R or ELAN 4 air motor
hose 5 m with hand control GA707R, ELAN 4 air wall adapters GA710R to
GA715R
Aesculap
®
ELAN 4 air m otor hose 3 m with hand co ntrol GA70 6R or ELAN 4 air motor hos e 5 m with han d control GA7 07R, ELAN 4 air wall adapters GA710R to GA715R
Legend
1 Connection for wall adapter
2 Field of vision “On“
3 Field of vision “Off“
4 Release button
5 Connection for applied part
6 Nib on motor hose
7 Hand lever
8 Connection for compressed-air source
9 Connection for motor hose (with hand control)
10 Groove on connection for motor hose
11 Connection for motor hose of applied part
12 Slider for tool release
Symbols on product and packages
Caution
Observe important safety information such as warnings
and precautions in the instructions for use.
YYYY-MM
Maintenance label
Recommended date of next service (format: YYYY-MM)
by international B. Braun-/Aesculap agents, see Technical
Service
Machine-readable, two-dimensional code
The code contains a unique serial number which can be
used for electronic tracking of the individual instrument.
The serial number is based on the global standard sGTIN
(GS1).
Date of manufacture
Manufacturer’s batch designation
Manufacturer’s serial number
Manufacturer’s article number
Temperature limits during transport and storage
Air humidity limits during transport and storage
Atmospheric pressure limits during transport and storage
LOT
SN
REF

Braun Aesculap ELAN 4 Specifications

General

Brand	Braun
Model	Aesculap ELAN 4
Category	Medical Equipment
Language	English
