System Components
PreciseFlex 400 Robot
NOTE: See Appendix J: Robot Anatomy for detailed illustrations.
The PreciseFlex 400 Robot (pictured in Figure 2-2 and defined in Table 2-2) is a 4-axis robot that
may optionally include an electric or pneumatic gripper.
Figure 2-2: PreciseFlex 400 Robot
Annotation Name Description
1 Base Plate Plate to attach robot to table
2 Z Column Vertical column
3 Shoulder Moves up and down column, rotates Inner Link
Table 2-2: PreciseFlex 400 Robot Details
