Appendices (Undefined variable: MyVariables.ProductName)
Appendix B: Environmental Spe-
cifications
Part Number: PF40-DI-00010 Rev. A
Appendix B: Environmental Specifications
NOTE: Our PreciseFlex robots are powered by 24 VDC and 48 VDC low-voltage DC
power supplies with built-in overcurrent protection. For this reason, the PreciseFlex
robots do not have an SCCR.
The PreciseFlex Robots must be installed in a clean, non-condensing environment with the
following specifications:
General Specification Range & Features
Ambient temperature 4º C to 40º C
Indoor use only
Storage and shipment temperature -25º C to +55º C
Humidity range 10 to 55%, non-condensing, non-corrosive
Altitude Up to 3000 m
Voltage 100-240 VAC +/- 10%, 50/60 Hz
Mains cord rating, min 18 AWG, 3 conductor, 5 Amps min
Pollution Degree 2
Approved Cleaning Agents IPA, 70% Ethanol/30% water, H2O2 Vapor up to 1000 ppm
IP rating 11
IK impact rating IK08: 5 Joule
Table 8-2: Environmental Specifications
159
Copyright © 2023, Brooks Automation
