Brooks Automation 6. Software Reference
Part Number: PF40-DI-00010 Rev. A Accessing the Web Server
Step Action
2.
It may be necessary to enter a password if a company has protected access to the web Interface.
Once the password has been entered, click Admin to access all the features to perform system
upgrades.
3.
Click Control Panels → Operator Control Panel.
4.
If an application is running, the “System Running” panel will display in green. In order to run
diagnostics, stop the application from running. Click Stop Application and then Perform Operation.
This will stop the application from running.
5.
Click Disable Power to be sure motor power is off.
6.
To load a new project (for example CAL_PP), click Unload and then Perform Operation before
loading the new project into RAM.
Copyright © 2023, Brooks Automation
76
