2007 Buell Lightning: Chassis 2-77

HOME

FRONT MODULES 2.29

REMOVAL

1. Remove seat. See 2.44 SEAT.

11WARNING1WARNING

To protect against accidental start-up of vehicle and pos-

sible personal injury, disconnect the negative battery

cable before proceeding. Inadequate safety precautions

could cause a battery explosion, which could result in

death or serious injury.

2. Disconnect battery by unthreading fastener removing

negative cable (black) from battery ﬁrst. See 1.4 BAT-

TERY MAINTENANCE.

3. Remove windscreen. See 2.43 WINDSCREEN.

4. Remove headlight assembly and support bracket. See

2.28 HEADLIGHT ASSEMBLY AND SUPPORT

BRACKET.

5. Disconnect and remove instrument module. See 7.19

INSTRUMENT MODULE.

6. Remove ignition switch. See 7.3 IGNITION/HEADLIGHT

KEY SWITCH.

NOTE

See Figure 2-110. Once the ignition switch has been

removed there will be two remaining fasteners.

7. See Figure 2-110. Remove fastener attaching p-clamp to

rear side of right front module.

NOTE

See Figure 2-111. Once the clamp load has been released

on the ﬁnal fastener securing the right front module to the

upper triple clamp, the left front module can be removed.

8. See Figure 2-110. Loosen but do not remove ﬁnal fas-

tener securing the right front module to upper triple

clamp.

9. See Figure 2-111. Remove the left front module.

10. See Figure 2-110. Remove the ﬁnal fastener and the

right front module.
