2007 Buell Lightning: Fuel System 4-107

HOME

FUEL PUMP 4.39

GENERAL

The fuel pump is located inside the left rear portion of the fuel

tank/frame.

DRAINING FUEL TANK

1WARNING1WARNING

To prevent spray of fuel, purge system of high-pressure

fuel before supply line is disconnected. Gasoline is

extremely ﬂammable and highly explosive, which could

result in death or serious injury. (00275a)

1. Purge the fuel supply line of high pressure gasoline.

a. See Figure 4-91. Disconnect the 4-place fuel pump

connector (1) [86]. Connector is located inside the

left rear portion of the fuel tank/frame.

b. With the motorcycle in neutral, start the engine and

allow vehicle to run.

c. When the engine stalls, press the starter button for 3

seconds to remove any remaining fuel from fuel line.

1WARNING1WARNING

Stop the engine when refueling or servicing the fuel sys-

tem. Do not smoke or allow open ﬂame or sparks near

gasoline. Gasoline is extremely ﬂammable and highly

explosive, which could result in death or serious injury.

(00002a)

2. Remove drain plug (4) and drain fuel into appropriate

container. Discard plug.

3. When fuel tank is empty, replace with new drain plug.

Tighten to 84-108 in-lbs (9.5-12.2 Nm).

Figure 4-91. Fuel Pump Installation

10718a

1. Connector [86]

2. Fuel supply ﬁtting

3. Fuel supply stud

4. Drain plug

5. Fasteners
