1-50 2007 Buell Lightning: Maintenance

HOME

THROTTLE POSITION SENSOR (TPS) 1.19

ADJUSTMENT

NOTE

If closed throttle TP degree reading is not between 5.1° - 6.2

degrees, TPS should be re-calibrated. See ADJUSTMENT

below.

1. Connect vehicle to Digital Technician.

2. Select calibrations screen/TPS Function.

3. Select Buell TPS zero tab.

4. Select TP volts on screen.

5. See Figure 1-61. Back off idle adjustment until TP volts

stop decreasing

and then continue to back out one full

turn.

6. Open and snap shut throttle control grip 2-3 times.

NOTE

This is to ensure that the throttle plate is completely closed

before beginning recalibration.

7. With ignition and run switch in the on position with

engine off and throttle in the closed position press the

TPS zero button at the bottom of the screen.

8. Select TPS zero button and perform TPS zero.

NOTE

When calibration is complete, dialogue box will appear on

Digital Tech screen with message display “Command Sent

Successfully”. Press OK.

9. Turn idle adjustment cable screw clockwise until TPS

degrees read 5.2-5.6 degrees.

10. Run vehicle until engine temperature is at 320

°F (160°

C).

11. Set idle to 1050-1150 RPM.

Figure 1-61. Idle Adjuster (behind left fork)

8390
