Buell 2007 LIGHTNING Service Manual

2007 Buell Lightning: Electrical 7-1
HOME
SPECIFICATIONS 7.1
Table 7-1. Battery Specifications
BATTERY
Size 12 VDC/12 AH/200CCA
Type Sealed, AGM
Table 7-2. Spark Plug Specifications
SPARK PLUGS
Size 12 mm
Type 10R12A
Gap 0.035 in. 0.9mm
Torque 11-18 ft-lbs 15-24 Nm
Cable resistance
(front and rear)
1,350-3,465 ohms
Table 7-3. Alternator Specifications
ALTERNATOR
AC voltage output 16-20 VAC per 1000 engine RPM
Stator coil resistance 0.1-0.3 Ohms
Table 7-4. Regulator Specifications
REGULATOR
Voltage output @ 3600 RPM 14.4-14.6 VDC@ 75° F
(24° C)
Amperes @ 3600 RPM 34 Amps
Table 7-5. Ignition Coil Specifications
IGNITION COIL RESISTANCE
Primary winding 0.5-0.7 ohms
Secondary winding 5500-7500 ohms
Table 7-6. Electrical System Specifications
ELECTRICAL SYSTEM AMPERES
Battery fuse 30
Ignition fuse 15
Light fuse 15
Accessory fuse 10
Brake/horn/active muffler fuse
(1200 models only)
10
ECM fuse 10
Key switch fuse 15
Cooling fan fuse 10
Table 7-7. Bulb Chart
BULB CHART
BULBS
REQUIRED
WATTS AMPS
PART
NUMBER
Headlights
Bulb (H7) 2 55 4.58 Y0148.1AD
Position lamp
(European models only)
1 5 0.37 53436-97
Marker lamps
Tail/Stop Lamp 1 5/21 0.42/1.75 68169-90A
Turn signal lamp (front and rear
1 bulb each)
4 10.0 0.74 Y0042.K
License plate illumination lamp
(European models only)
1 5 0.37 53436-97

Buell 2007 LIGHTNING Specifications

General

Year	2007
Manufacturer	Buell
Model	Lightning
Category	Motorcycle
Displacement	1203 cc
Bore x Stroke	88.9 mm x 96.8 mm
Compression Ratio	10.0:1
Fuel System	Electronic fuel injection
Transmission	5-speed
Final Drive	Belt
Rear Suspension	Showa shock absorber
Rear Brakes	Single disc, 1-piston caliper
Engine Type	V-Twin
Ignition	Digital
Front Suspension	Showa inverted fork
Front Brakes	Single disc, 6-piston caliper
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Wheelbase	52.0 inches
Seat Height	30.1 inches
Dry Weight	395 lbs
Fuel Capacity	14.5 liters
