Buell 2007 LIGHTNING Service Manual

2-82 2007 Buell Lightning: Chassis
HOME
MIRRORS 2.31
REMOVAL
1. See Figure 2-113. Loosen adjuster nut (2) and remove
mirror (1) from mount (3).
2. Loosen mount (3) and remove from bracket (4).
INSTALLATION
1. See Figure 2-113. Install mount (3) onto bracket (4) and
tighten to 20-22 ft-lbs (27.1-29.8 Nm).
NOTE
In a convex mirror, cars and other objects will look smaller
and farther away than they actually are. Adjust mirrors to see
a small portion of the riders shoulders in each mirror. This
helps the rider establish the relative distance of vehicles to
the rear of the motorcycle.
2. Install mirror (1) and while holding in position for rider
vision, tighten adjuster to 115-130 in-lbs (13-14.7 Nm).
Figure 2-113. Mirrors and Mounting Hardware (Typical)
1. Mirror
2. Adjuster nut
3. Mount
4. Bracket
1
1
2
3
3
4
9990
2

Buell 2007 LIGHTNING Specifications

General

Year	2007
Manufacturer	Buell
Model	Lightning
Category	Motorcycle
Displacement	1203 cc
Bore x Stroke	88.9 mm x 96.8 mm
Compression Ratio	10.0:1
Fuel System	Electronic fuel injection
Transmission	5-speed
Final Drive	Belt
Rear Suspension	Showa shock absorber
Rear Brakes	Single disc, 1-piston caliper
Engine Type	V-Twin
Ignition	Digital
Front Suspension	Showa inverted fork
Front Brakes	Single disc, 6-piston caliper
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Wheelbase	52.0 inches
Seat Height	30.1 inches
Dry Weight	395 lbs
Fuel Capacity	14.5 liters
