2007 Buell Lightning: Electrical 7-51

HOME

TURN SIGNAL FLASHER 7.16

REMOVAL

NOTE

The turn signal ﬂasher is not repairable. Replace ﬂasher upon

failure.

1. Remove windscreen. See 2.43 WINDSCREEN.

2. Remove fastener securing turn signal ﬂasher to front

module.

3. See Figure 7-63. Detach 5-place connector [30] from

ﬂasher body.

INSTALLATION

1. See Figure 7-63. Attach 5-place connector [30] to

ﬂasher.

2. Install turn signal ﬂasher to front module. Tighten fas-

tener to 12-36 in-lbs (1.4-4 Nm).

1WARNING1WARNING

Be sure that all lights and switches operate properly

before operating motorcycle. Low visibility of rider can

result in death or serious injury. (00316a)

3. Check turn signals for proper operation. If operation fails,

reread procedure and verify that all steps were per-

formed.

a. Turn ignition key switch to ON.

b. See Figure 7-64. Activate left turn signals using

switch on left handlebar. Front and rear left turn sig-

nals must ﬂash.

c. Activate right turn signals using switch on left han-

dlebar. Front and rear right turn signals must ﬂash.

d. Turn ignition key switch to OFF.

4. Install windscreen. See 2.43 WINDSCREEN.

Figure 7-63. Turn Signal Flasher

Figure 7-64. Turn Signal Controls

12155a

b0586x0x

1. Left turn signal

2. Right turn signal
