Buell 2007 LIGHTNING Service Manual

2007 Buell Lightning: Chassis 2-1
HOME
SPECIFICATIONS 2.1
NOTE
Gross Vehicle Weight Rating (GVWR) (maximum allowable
loaded vehicle weight) and corresponding Gross Axle Weight
Ratings (GAWR) are given on an information decal located
on the steering head.
Table 2-1. Dimensions
DIMENSIONS IN. MM
Wheel base (XB12Ss) 54.0 1372
Wheel base (All other models) 52.0 1320
Seat height (XB12S) 30.1 765
Seat height (XB9SX) 31.4 798
Seat height (XB12Scg) 28.6 726
Seat height (XB12Ss) 30.5 775
Ground clearance
(XB12S & XB9SX)
4.35 110
Ground clearance (XB12Scg) 3.55 90
Ground clearance (XB12Ss) 4.66 118
Trail (XB9SX, XB12S, XB12Scg) 3.3 83
Trail (XB12Ss) 4.7 119
Rake (XB9SX, XB12S,
XB12Scg)
21 Degrees
Rake (XB12Ss) 22 Degrees
Table 2-2. Weight Specifications (1203cc)
WEIGHT-U.S. MODELS LBS. KG
Wet weight (XB12S,
XB12Scg)
462 210
Wet weight (XB12Ss) 465 211
GVWR (all models) 850 386
GAWR - front (all models) 315 143
GAWR - rear (all models) 535 243
Load capacity (XB12S,
XB12Scg)
388 176
Load capacity (XB12Ss) 385 175
Table 2-3. Weight Specifications (984cc)
WEIGHT-U.S. MODELS LBS. KG
Wet weight 452 205
GVWR 850 386
GAWR - front 315 143
GAWR - rear 535 243
Load capacity 398 181
Table 2-4. Capacities
CAPACITIES U.S. LITERS
Fuel tank (inc. reserve)
(XB9SX, XB12S, XB12Scg)
3.82 gallons 14.5
Reserve/Low fuel light at
(XB9SX, XB12S, XB12Scg)
0.75 gallons 2.8
Fuel tank (inc. reserve)
(XB12Ss)
4.40 16.7
Reserve/Low fuel light at
(XB12Ss)
0.83 3.1
Oil tank
(wet - for normal oil change)
2.5 quarts 2.4
Fork oil (each fork) 16 ounces 0.47
Transmission 1.0 quart 0.95
Table 2-5. Tire and Positions
TIRE AND POSITION
SOLO
RIDING
GVWR
Front
Pirelli Diablo T
120/70 ZR 17
34 PSI
(248
kPa)
Same
as solo
Front
Pirelli Scorpion Sync
(XB9SX only) 120/70 ZR 17
34 psi
(234
kPa)
Rear
Pirelli Diablo T
ss180/55 ZR 17
36PSI
(262
kPa)
Rear
Pirelli Scorpion Sync
(XB9SX only) 180/55 ZR 17
36 psi
(248
kPa)
Table 2-6. Brake Rotor Runout
RUNOUT IN. MM
Front radial 0.0177 0.45
Front lateral 0.0248 0.63
Rear radial 0.0177 0.45
Rear lateral 0.0154 0.39

Buell 2007 LIGHTNING Specifications

General

Year	2007
Manufacturer	Buell
Model	Lightning
Category	Motorcycle
Displacement	1203 cc
Bore x Stroke	88.9 mm x 96.8 mm
Compression Ratio	10.0:1
Fuel System	Electronic fuel injection
Transmission	5-speed
Final Drive	Belt
Rear Suspension	Showa shock absorber
Rear Brakes	Single disc, 1-piston caliper
Engine Type	V-Twin
Ignition	Digital
Front Suspension	Showa inverted fork
Front Brakes	Single disc, 6-piston caliper
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Wheelbase	52.0 inches
Seat Height	30.1 inches
Dry Weight	395 lbs
Fuel Capacity	14.5 liters
