2-100 2007 Buell Lightning: Chassis
HOME
Figure 2-127. Right Side Frame Section (Typical)
1. Right front trunk pan fastener
2. Passenger footrest support fastener with jam nut
3. Ground terminals [GRD1] & [GRD 3]
4. Rear brake light switch connector [121]
5. Right tail section
6. Center tail section fastener to rear tail section
8907
1
3
2
4
6
5
