2007 Buell Lightning: Engine 3-5
HOME
Oil pressure signal light switch 50-70
in-lbs
5.6-7.9 Nm page 3-79
Oil pump cover screws 70-80
in-lbs
8-9 Nm TORX, page 3-85
Oil pump mounting screws 125-150
in-lbs
14-17 Nm Page 3-85
Pinion shaft nut 19-21 ft-lbs 26-29 Nm
plus an additional 15º to 19º rotation, LOCTITE
271 (red), page 3-92
Piston jet TORX screws 25-35
in-lbs
2.8-4 Nm Loctite 222 (purple), page 3-95
Pushrod cover screws 30-40
in-lbs
3-5 Nm page 3-88
Rear isolator assembly fasten-
ers
25-27 ft-lbs 33.9-36.6 Nm page 3-29
Rear isolator bolt 25-27 ft-lbs 33.9-36.6 Nm page 3-32
Rear muffler bracket 32-36 ft-lbs 43.4-48.8 Nm LOCTITE 271 (red), page 3-33
Reed block fasteners 25-35
in-lbs
2.8-4 Nm LOCTITE 222 (purple), page 3-81
Reed valve stop fastener 5-7
in-lbs
0.6-0.8 Nm LOCTITE 222 (purple), page 3-81
Return oil line at top front oil
pump
22-24 ft-lbs 29.8-32.5 Nm page 3-35
Rocker box cover screws 120-168
in-lbs
13.6-18.9 Nm page 3-60
Rocker box to head bolts 135-155
in-lbs
15-18 Nm Small bolt (3), page 3-60
Rocker box to head bolts 18-22 ft-lbs 24-30 Nm Large fasteners, page 3-60
Rocker box to head screws 135-155
in-lbs
15-18 Nm Small screw (2), page 3-60
Stabilizer bracket fastener 66-78
in-lbs
7.5-8.8 Nm page 3-76
Swingarm pivot shaft pinch
bolt
17-19 ft-lbs 23-25.8 Nm page 3-30
Swingarm pivot shaft 24-26 ft-lbs 32.5-35.2 Nm page 3-30
V bracket to main frame 120-144
in-lbs
13.6-16.3 Nm page 3-14, 3-32
Vent oil line at gearcase cover 12-13 ft-lbs 16.3-17.6 Nm page 3-35
ITEM TORQUE NOTES
