Buell 2007 LIGHTNING Service Manual

2007 Buell Lightning: Starter 5-7
HOME
Starter Test 5: Starter Spins But Does Not Engage
Starter Test 6: Starter Stalls or Spins Too Slowly
Remove starter. Disassemble drive housing
assembly. Inspect for damage to armature
gear or idler gear. Damage present?
Replace damaged idler
gear and armature.
YES
Starter clutch failure.
Replace starter clutch.
NO
5837
5825
Perform voltage drop tests
between battery positive to
starter battery terminal.
Crank engine.
Voltage greater than 1 volt?
YES
5824
Perform voltage drop tests from battery
positive to starter motor terminal. Crank
engine. Voltage greater than 1 volt?
NO
Repair connection
between battery and
starter.
YES
Repair or replace
solenoid (contacts).
NO
Perform voltage drop tests
between battery negative and
starter studs or bolts.
Voltage greater than 1 volt?
Clean ground
connections.
YES
Perform starter motor current
draw test (on vehicle).
Perform starter motor free draw
bench test.
Are test results within range?
NO
Remove spark plugs while in
5th gear. Rotate rear wheel.
Check for engine, primary
and/or crankshaft bind.
YES
Test starter motor for
opens, shorts or grounds.
Replace or repair starter
motor.
NO
5845
5835
5817
Use appropriate code
1
1
4
5

Buell 2007 LIGHTNING Specifications

General

Year	2007
Manufacturer	Buell
Model	Lightning
Category	Motorcycle
Displacement	1203 cc
Bore x Stroke	88.9 mm x 96.8 mm
Compression Ratio	10.0:1
Fuel System	Electronic fuel injection
Transmission	5-speed
Final Drive	Belt
Rear Suspension	Showa shock absorber
Rear Brakes	Single disc, 1-piston caliper
Engine Type	V-Twin
Ignition	Digital
Front Suspension	Showa inverted fork
Front Brakes	Single disc, 6-piston caliper
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Wheelbase	52.0 inches
Seat Height	30.1 inches
Dry Weight	395 lbs
Fuel Capacity	14.5 liters
