7-44 2007 Buell Lightning: Electrical
HOME
9. See Figure 7-52. Check headlight for proper operation. If
operation fails, reread procedure and verify that all steps
were performed.
a. Turn ignition key switch to ON.
b. Check headlight LOW (3) and HIGH beam (2) set-
tings.
c. Set headlight to LOW beam. Press passing lamp
switch (1). Headlight should flash HIGH beam for as
long as the switch is pressed.
d. Turn ignition key switch to OFF.
10. Install seat. See 2.44 SEAT
1WARNING1WARNING
After installing seat, pull upward on front of seat to be
sure it is in locked position. While riding, a loose seat can
shift causing loss of control, which could result in death
or serious injury. (00070a)
11. Align headlight. See 1.18 HEADLIGHTS.
Figure 7-52. Headlight Controls
1. Passing lamp switch
2. HIGH beam
3. LOW beam (always on when bike is running)
b0586x0x
1
3
2
