Buell 2007 LIGHTNING Service Manual

2007 Buell Lightning: Appendix B B-15
HOME
[121] front brake switch 2-place Multilock
underside of front master cylinder
assembly
[121] rear brake switch 2-place Multilock under seat
[122] horn 2-spade terminals behind windscreen
[128] starter solenoid spade terminal top of starter
[131] neutral switch 1-place bullet under sprocket cover
[134] bank angle sensor 6-place Sumitomo under seat
[137] oxygen sensor 1-place Packard behind rear cylinder head
[161] Interactive exhaust to actuator 4-place Amp
under air cleaner assembly baseplate
cover
[164] Interactive exhaust circuit to ECM spade terminal under seat
[165]
Interactive exhaust harness to main
harness
3-place Deutsch under seat
[178] Active intake system to solenoid
under air cleaner assembly baseplate
cove
[179] Active intake system to ECM under seat
Table B-2. Electrical Connector and Location Table
CONNECTOR COMPONENT(S) DESCRIPTION LOCATION

Buell 2007 LIGHTNING Specifications

General

Year	2007
Manufacturer	Buell
Model	Lightning
Category	Motorcycle
Displacement	1203 cc
Bore x Stroke	88.9 mm x 96.8 mm
Compression Ratio	10.0:1
Fuel System	Electronic fuel injection
Transmission	5-speed
Final Drive	Belt
Rear Suspension	Showa shock absorber
Rear Brakes	Single disc, 1-piston caliper
Engine Type	V-Twin
Ignition	Digital
Front Suspension	Showa inverted fork
Front Brakes	Single disc, 6-piston caliper
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Wheelbase	52.0 inches
Seat Height	30.1 inches
Dry Weight	395 lbs
Fuel Capacity	14.5 liters
