2007 Buell Lightning: Chassis 2-3
HOME
Deflector, pivot shaft jam nut 39-48
in-lbs
4.4-5.4 Nm page 2-68
Engine shift lever pinch screw 48-60
in-lbs
5.4-6.8 Nm LOCTITE 271 (red), Page 2-71
Engine shroud air scoop 12-36
in-lbs
1-4 Nm page 2-93
Exhaust header mounting nut 72-96
in-lbs
8-11 Nm page 2-85
Footpeg mount fasteners,
rider
132-144
in-lbs
14.9-16.2 Nm page 2-86
Footpeg mount, passenger 25-28 ft-lbs 33.8-37.9 Nm LOCTITE 271 (red), page 2-87
Fork cap to damper rod 38-42 ft-lbs 51-57 Nm page 2-51
Fork cap to fork tube 22-30 ft-lbs 29.8-40.6 Nm page 2-51
Fork center bolt 22-30 ft-lbs 30-40 Nm page 2-50
Fork clamp, lower 20-22 ft-lbs 27.2-20 Nm LOCTITE 271 (red), page 2-52
Fork clamp, upper 23-25 ft-lbs 31.2-33.8 Nm LOCTITE 271 (red), page 2-52,2-54
Fork damper locknut 22-30 ft-lbs 30-40 Nm page 2-50
Front fender fasteners 36-48
in-lbs
4-5.4 Nm LOCTITE 271 (red), page 2-89
Front isolator bolt 49-51 ft-lbs 66-69 Nm page 2-62
Front isolator bracket mount-
ing fasteners
49-51 ft-lbs 66-69 Nm page 2-62
Front isolator snubber, upper 12-36
in-lbs
1-4 Nm page 2-62
Front isolator threaded frame
insert
59-61 ft-lbs 80-82.7 Nm LOCTITE 271, page 2-62
Front muffler mount 16-18 ft-lbs 1.7-24.4 Nm page 2-85
Hand lever pivot fastener 39-48
in-lbs
4.4-5.4 Nm (XB9SX models only), page 2-29
Hand lever pivot fastener 80-120
in-lbs
9-13.5 Nm (All other models) , page 2-29
Handlebar clamp screws 10-12 ft-lbs 14-16 Nm
LOCTITE 271 (red), tighten front screws first,
page 2-80
Headlight support bracket fas-
teners
48-72
in-lbs
5.4-8.1 Nm LOCTITE 271, page 2-76
Heel guard fasteners, passen-
ger
48-72
in-lbs
5.4-8 Nm page 2-87
Heel guard fasteners, rider 72-96
in-lbs
8-11 Nm page 2-86
Horn 72-96
in-lbs
8-10.8 Nm page 2-76
Master cylinder banjo bolt,
front
16-20 ft-lbs 22-27 Nm page 2-32
Master cylinder cover fasten-
ers, front
9-13
in-lbs
1.0-1.5 Nm page 2-30
Master cylinder mounting fas-
teners, rear
72-96
in-lbs
8-11 Nm page 2-39
Mirror adjuster 115-130
in-lbs
3-14.7 Nm page 2-82
Mirror mount onto bracket 20-22 ft-lbs 27.1-29.8 Nm page 2-82
Muffler mounting block fas-
tener, rear
32-36 ft-lbs 43-49 Nm LOCTITE 271 (red), page 2-85
Muffler strap fastener, front 108-120
in-lbs
12-14 Nm page 2-85
Muffler strap fastener, rear 48-60
in-lbs
5-7 Nm page 2-85
ITEM TORQUE NOTES
