2007 Buell Lightning: Appendix D D-5
HOME
Figure D-5. Evaporative Emissions Control, California and 49 State Models, Left Side View
1. To induction module
2. From induction module (California)
3. From fuel tank (California)
4. From fuel tank to atmosphere (49 state)
1
b1118xbsxL
2
3
4
