2007 Buell Lightning: Appendix D D-9
HOME
Figure D-9. Oil Lines, Right Side View
2
3
4
5
1. Vent line
2. Feed oil line
3. Return oil line
4. Feed oil line from the oil pump to the oil cooler
5. Return oil line from the oil cooler to the oil filter housing
b1122xasxL
1
