3-18 2007 Buell P3: Engine
HOME
13. See Figure 3-29. Connect feed, return, transmission and
crankcase vent lines.
14. See Figure 3-30. Tighten hose clamps using Hose
Clamp Pliers (Part No. HD-41137).
15. See Figure 3-31. Tighten nut on hose routing clamp.
16. Install rear shock. See 2.15 REAR SHOCK ABSORBER.
17. Refer to Table 3-20. Connect the following electrical
items:
Figure 3-29. Connect Lines
Figure 3-30. Tighten Hose Clamps
7634
1. Oil return
2. Transmission vent
3. Crankcase vent
4. Feed
4
2
1
3
7635
Figure 3-31. Tighten Clamp
7718
