7. Setting up communications
with the data logger
The first step in setting up and communicating with your data logger is to configure your
connection. Communications peripherals, data loggers, and software must all be configured for
communications.
The default settings for the data logger allow it to communicate with a computer via USB, RS-
232, or Ethernet (on CR310 models). For other communications methods or more complex
applications, some settings may need adjustment. Settings can be changed through Device
Configuration Utility or through data logger support software.
You can configure your connection using any of the following options. The simplest is via USB.
For detailed instruction, see:
l
USB or RS-232 communications(p. 21)
l
Virtual Ethernet over USB (RNDIS)(p. 24)
l
Ethernet communications option(p. 26) (CR310 models only)
l
Wi-Fi communications option(p. 29) (WIFI models only)
l
Cellular communications option(p. 37) (CELLmodels only)
l
Radio communications option(p. 52) (RF models only)
For other configurations, see the LoggerNet EZSetup Wizard help. Context-specific help is given
in each step of the wizard by clicking the Help button in the bottom right corner of the window.
For complex data logger networks, use Network Planner. For more information on using the
Network Planner, watch a video at https://www.campbellsci.com/videos/loggernet-software-
network-planner .
Additional information is found in your specific peripheral manual, and the data logger support
software manual and help. See also:
l
www.campbellsci.com/cellular-communications for links to CELL200-series, RV50X,
cellular data services, Konect PakBus router, and other cellular products
l
www.campbellsci.com/wi-fi-communications for links to the NL241, and other Wi-Fi
products
l
www.campbellsci.com/spread-spectrum-radios for links to the RF452 and RF407-series
spread spectrum radios
7. Setting up communications with the data logger19
