Campbell CR310 User Manual

12.1.2 Install the SIM card
1. Remove the SIM card cover.
2. Note the location of the notched corner for correct alignment. The gold contact points of
the SIM face down when inserting the SIM card as shown in the following figure. Gently
slide the card into the slot until it stops and locks into place. To eject the SIM card, press it
in slightly and release.
3. Replace the SIM card cover.
Figure 12-1. SIM card installation
12.1.3 Konect PakBus Router setup
12.1.3.1 Get started
You will need the Konect PakBus Router redemption code that came on a card with the CR300-
CELL.
Open a web browser and go to www.konectgds.com .
12. Cellular communications option39

Campbell CR310 Specifications

General

Brand	Campbell
Model	CR310
Category	Data Loggers
Language	English
