Handling rolls
Handling rolls
Selecting the Roll as the Paper Source
Y ou can switch between manual and auto paper feed methods by pressing the Feeder Selection button.
The Auto Feed lamp is lit when feeding paper automatically , and the Paper T ray lamp is lit when feeding
paper manually .
Y ou must specify auto feed when using rolls. Press the Feeder Selection button to activate the Auto Feed
lamp (a).
Caution
• Paper jams may occur if you load paper other than the paper specied in the paper settings for the
media source.
Note
• Y ou cannot switch the paper source in the following situations:
• If the Message lamp is ashing
Check the message on the Display Screen and take action as necessary . ( → P .729)
• If the Data lamp is ashing
Select the paper source after printing is nished.
• If a printer menu operation is in progress
Select the paper source after the operation is nished.
• When in the process of loading paper
Finish loading the paper before selecting the paper source.
• When in the process of replacing Ink T anks
Finish replacing the Ink T anks before selecting the paper source.
• If the T op Cover is open
Close the T op Cover before selecting the paper source.
At this point, load the roll. ( → P .1 18)
Note
• If any paper is loaded that will not be used, remove it before loading the roll.
( → P .122)
( → P .172)
• When printing on rolls after printing on sheets, make sure that no printed documents are left on the
Output T ray and that the V ertical Paper Guides are stored out of the way . If you print without checking
this, the Front T ray Guides may become caught inside the Front Paper Feed Slot . ( → P .726 )
1 14 Handling Paper
