Canon imagePROGRAF iPF5100 - Loading Rolls in the Roll Feed Unit

Handling rolls
Loading Rolls in the Roll Feed Unit
1. Push in the Output T ray Extension .
2. Insert your ngers under the V ertical Paper Guides on the Output T ray at the positions shown
(a) and lift the guides.
3. Open the Roll Paper Unit Cover with one hand, as shown.
1 18 Handling Paper
