Adjusting the feed amount
2. Press the Menu button to display MAIN MENU .
3. Press ◄ or ► to select Adjust Printer , and then press the ▼ button.
MAIN MENU
Adjust Printer ↓
4. Press ◄ or ► to select Manual Band Adj , and then press the ▼ button.
Adjust Printer
Manual Band Adj ↓
5. Press ◄ or ► to select Y es , and then press the OK button.
The setting is updated, and an equals sign “=” is displayed at left.
Manual Band Adj
= Y es
T est pattern A is printed for band adjustment.
6. Examine test pattern A for band adjustment. After you determine the pattern in which streaks are
least noticeable, press ◄ or ► to choose the pattern number , and then press the OK button.
Adj.Setting
=8
T est pattern B is printed for band adjustment.
Note
• If streaks seem least noticeable in two patterns but you cannot decide which one is better , choose an
intermediate value. For example, choose 1 1 if you cannot decide whether pattern 10 or 12 is better .
620 Maintenance
