Case 621G - Page 113

To Next Page

To Previous Page

3-CONTROLSANDINSTRUMENTS

AuxHydraulics

Usethekeypadontheright-handofthedisplaytoselect

thekeytoswitchtothe“AuxiliaryHydraulics”settings.

LEIL18WHL1218AA28

→AuxHydraulicsselections

Aux1FlowControl

LEIL15WHL0534AA29

Lighting

Usethekeypadontheright-handofthedisplaytoselect

thekeytoswitchtothe“Lighting”settings.

LEIL18WHL1091AA30

→Lightingselections

FollowMeHome

FollowMeHomeInterval

LEIL18WHL1220AA31

3-53
