3-CONTROLSANDINSTRUMENTS

Fan

Usethekeypadontheright-handofthedisplaytoselect

thekeytoswitchtothe“Fan”settings.

LEIL18WHL1216AA24

→Fanselections

AutoFan

FanReverserInterval

FanReverserDuration

LEIL15WHL0532AA25

JoystickSteering

Usethekeypadontheright-handofthedisplaytoselect

thekeytoswitchtothe“JoystickSteering”settings.

LEIL18WHL1217AA26

→JoystickSteeringselections

JoystickSteering

LEIL15WHL0533AA27
