3-CONTROLSANDINSTRUMENTS

Security

Usethekeypadontheright-handofthedisplaytoselect

thekeytoswitchtothe“Security”page.

LEIL16WHL0933AA88

→Enable/Disable

Defaultoptionisselected.

LEIL16WHL1543AA89

→CreatePasscode

Passcodecreationinthesecuritypagehasthreelevels:

1.Selecttheuserlevelbetweenbasic,advancedand

admin(seetable“Accesslevelsummery”foraccessible

featuresbyeachuserlevel).

LEIL16WHL1547AA90

2.Assignadefaultorcustomnametothepasscode.

LEIL16WHL1548AA91

3-68
