Case 621G - Page 139

3-CONTROLSANDINSTRUMENTS
9.Joysticksteeringindicator(ifequipped,
green)
Theindicatorilluminateswhenthejoystick
steeringfunctionisactive.
10.Differentiallockindicator(green)
Theindicatorilluminateswhenthe
automaticdifferentiallockfunctionis
enabledviamultifunctionkeypad.
11.Hydraulicfunctionsindicator(red)
Theindicatorilluminateswhenhydraulic
functionsareblocked.
12.Toolbar
13.Digitalclock
14.Informationongear
15.Hoursofuseofthemachine
16.DIESELEXHAUSTFLUID(DEF)/ADBLUE®
levelgauge
TheDEF/ADBLUE®levelbargauge
indicatesthelevelofdieselexhaustuid
intheDEF/ADBLUE®tank.Whenallbars
areilluminated,thetankisfull.Illuminated
barsindicatethelevelofuidremainingin
theDEF/ADBLUE®tank.Whenthetank
isat5–10%oftankvolume,thewarning
systemwillashand/orwillashand
soundanaudiblealarmdependentupon
DEF/ADBLUE®levels.
LEIL15WHL0575AA4
DEF/ADBLUE®levelgauge
GaugeindicationCondition
MasterindicatorAlarmstatus
6-10%
Noenginepowerloss
Caution(yellow)
None
5%andbelow
Moderateenginepower
loss
Stop(red)Continuous
Empty
Severeenginepowerloss-
enginewillnotshutdown
Stop(red)Continuous
3-79
