3-CONTROLSANDINSTRUMENTS
17.Enginecoolanttemperaturegauge
Theenginecoolanttemperaturegauge
indicatesthecoolanttemperatureof
theengine.Whentheenginecoolant
temperaturecontinuestoincreaseand
thegaugemovesintotheredzone,the
warningalarmsoundscontinuously.The
stopmasterindicatorturnsred.Donot
operatethemachinewhenthetemperature
isintheredzone.
LEIL15WHL0576AA5
18.Transmissionoiltemperaturegauge
Thetransmissionoiltemperaturegauge
indicatestheoiltemperatureofthe
transmission.
Whenthetransmissionoiltemperaturecontinuestoin-
creaseandthegaugemovesintotheredzone,thewarn-
ingalarmsoundscontinuously.Thestopmasterindicator
turnsred.Donotoperatethemachinewhenthetemper-
atureisintheredzone.
LEIL15WHL0577AA6
NOTE:topreventdamagetothetransmission,stopthemachine,shiftthetransmissiontoNEUTRALandrunthe
engineatpartialthrottle(approximately1700RPM)untilthetransmissioncools.Ifthetransmissionoiltemperature
doesnotreturntonormaloperatingtemperature,runtheengineatidlespeedandcheckthetransmissionoillevel.
Correcttheproblembeforecontinuingtooperatethemachine.
19.Fuellevelgauge
WARNING
Pressurizedhydraulicuidcanpenetratethe
skinandcausesevereinjuries.
Ifthemachinerunsoutoffuel,donotattempt
toworkonpressurizedhydrauliclines.Lines
areunderhighpressure.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0372A
Thefuellevelgaugeindicatesthefuellevel.
Whenthetankisalmostempty,thegauge
movesintotheredzone,thefuelindicator
turnsonandthewarningalarmsounds.
NOTICE:donotallowthemachinetoruncompletelyout
offuel.
LEIL15WHL0578AA7
