Bucketheightcontrol
Usethebucketheightcontroltoautomaticallystopthe
loaderarmsattheheightselectedwhiletravelingupward.
Toenablethebucketheightcontrolpressthebutton(2).
ThegreenLEDindicatorlightsuptoindicatethatthefunc-
tionisactive.
Tosetthebucketheightcontrolproceedasfollows:
1.Brieypressthecorrespondingbutton(2)onthemul-
tifunctionkeypadtoactivatethefunction;thegreen
LEDindicatorlightsuptoindicatethatthefunctionis
active.
2.Settheattachmentorthebuckettothedesiredloca-
tion.
3.Pressandholdthebutton(2)onthemultifunctionkey-
paduntilthegreenLEDindicatorlightashes(approx-
imately2s).
4.Thebucketheightcontrolfunctionisnowset.Display
willpromptthatthedetentpositionissaved.
LEIL16WHL1130AB4
Toactuatethebucketheightcontrolfunction,movethe
joystickfullbackintotheRAISEpositionuntilthefunc-
tionactivationpointisreached.Whenthefunctionactiva-
tionpointisreached,theoperatorwillnoticemoreresis-
tancefromthejoystick.Ifreleased,thejoystickwillauto-
maticallyreturntotheHOLD(central)positionandthelift
armswillcontinuetoraiseuntilthearmsreachthedesired
height.Ifyoumovethejoystickwhenthebucketheight
controlfunctionisactivated,theloaderarmswillstop.
LEIL17WHL2055AB5
