4-OPERATINGINSTRUCTIONS

Auxiliaryhydraulicconnection(ifequipped)

WARNING

Escapinguid!

Donotdisconnecthydraulicquickcouplerunderpressurizedconditions.Makesureallhydraulic

pressureisremovedfromthesystembeforedisconnectinghydraulicquickcoupler.

Failuretocomplycouldresultindeathorseriousinjury.

W0095A

Yourwheelloadermaybeequippedwithanauxiliaryhy-

draulicsystem.

LEIL16WHL1447AB14

4-32
