8-SPECIFICATIONS
LEIL16WHL0630FB20
621GXTSpecications-2.3m³(3.0yd³)Blade/2.1m³(2.8yd³)TeethwithACSCoupler
BucketwithBolt-onEdgeBucketwithteeth
ISOBucketSpecications
Capacity(heaped)2.29m³(3.00yd³)2.14m³(2.80yd³)
Bucketwidth(maximumouter)2602mm(102.4in)2593mm(102.1in)
DimensionalOutlineSpecications
A(topofcabheight)3383mm(133.2in)3383mm(133.2in)
B(wheelbase)2900mm(114.2in)2900mm(114.2in)
C(groundclearance)389mm(15.3in)389mm(15.3in)
D(rearangleofdeparture)25°25°
Overallwidthw/obucket2478mm(97.6in)2478mm(97.6in)
Centerlinetreadwidth1950mm(76.8in)1950mm(76.8in)
Turningradius(outsideoftires)5223mm(205.6in)5223mm(205.6in)
Turninganglefromcenter40°40°
Totalturningangle
80°80°
E(fullyraisedwithspillguard)5387mm(212.1in)5387mm(212.1in)
F(hingepin-fullyraised)3959mm(155.9in)3959mm(155.9in)
G(overall-bucketlevelonground)7666mm(301.8in)7810mm(307.5in)
H(dump-fullyraised,45°dump)2745mm(108.1in)2653mm(104.4in)
J(reach-fullyraised,45°dump)1293mm(50.9in)1399mm(55.1in)
K(reach-2.13m(7.0ft),45°dump)1776mm(69.9in)1826mm(71.9in)
L(digdepth)63mm(2.5in)65mm(2.6in)
ISOLoadSpecications
OperatingWeight(withoutload)13541kg(29852lb)13505kg(29774lb)
Operatingload3605kg(7947lb)3654kg(8055lb)
Tippingload
Machinestraight
40°turn
8619kg(19002lb)
7210kg(15895lb)
8727kg(19241lb)
7307kg(16110lb)
