8-SPECIFICATIONS
LEIL16WHL0630FB21
621GXTSpecications-1.9m³(2.5yd³)Blade/1.8m³(2.4yd³)TeethwithJRBCoupler
BucketwithBolt-onEdgeBucketwithteeth
ISOBucketSpecications
Capacity(heaped)1.91m³(2.50yd³)1.83m³(2.40yd³)
Bucketwidth(maximumouter)2602mm(102.4in)2593mm(102.1in)
DimensionalOutlineSpecications
A(topofcabheight)3383mm(133.2in)3383mm(133.2in)
B(wheelbase)2900mm(114.2in)2900mm(114.2in)
C(groundclearance)389mm(15.3in)389mm(15.3in)
D(rearangleofdeparture)25°25°
Overallwidthw/obucket2478mm(97.6in)2478mm(97.6in)
Centerlinetreadwidth1950mm(76.8in)1950mm(76.8in)
Turningradius(outsideoftires)5223mm(205.6in)5223mm(205.6in)
Turninganglefromcenter40°40°
Totalturningangle
80°80°
E(fullyraisedwithspillguard)5386mm(212.0in)5386mm(212.0in)
F(hingepin-fullyraised)3960mm(155.9in)3960mm(155.9in)
G(overall-bucketlevelonground)7676mm(302.2in)7817mm(307.7in)
H(dump-fullyraised,45°dump)2739mm(107.8in)2648mm(104.3in)
J(reach-fullyraised,45°dump)1301mm(51.2in)1402mm(55.2in)
K(reach-2.13m(7.0ft),45°dump)1780mm(70.1in)1827mm(71.9in)
L(digdepth)62mm(2.4in)66mm(2.6in)
ISOLoadSpecications
OperatingWeight(withoutload)13305kg(29332lb)13269kg(29253lb)
Operatingload3596kg(7928lb)3482kg(7677lb)
Tippingload
Machinestraight
40°turn
8562kg(18877lb)
7193kg(15857lb)
8283kg(18262lb)
6964kg(15354lb)
