Case 621G - Page 416

8-SPECIFICATIONS
LEIL16WHL0630FB37
721GXTSpecications-2.3m³(3.0yd³)Blade/2.1m³(2.8yd³)TeethwithACSCoupler
BucketwithBolt-onEdgeBucketwithteeth
ISOBucketSpecications
Capacity(heaped)2.29m³(3.00yd³)2.14m³(2.80yd³)
Bucketwidth(maximumouter)2700mm(106.3in)2713mm(106.8in)
DimensionalOutlineSpecications
A(topofcabheight)3377mm(133.0in)3377mm(133.0in)
B(wheelbase)3253mm(128.1in)3253mm(128.1in)
C(groundclearance)384mm(15.1in)384mm(15.1in)
D(rearangleofdeparture)29°29°
Overallwidthw/obucket2558mm(100.7in)2558mm(100.7in)
Centerlinetreadwidth2030mm(79.9in)2030mm(79.9in)
Turningradius(outsideoftires)5748mm(226.3in)5748mm(226.3in)
Turninganglefromcenter40°40°
Totalturningangle
80°80°
E(fullyraisedwithspillguard)5563mm(219.0in)5563mm(219.0in)
F(hingepin-fullyraised)4155mm(163.6in)4155mm(163.6in)
G(overall-bucketlevelonground)8006mm(315.2in)8152mm(320.9in)
H(dump-fullyraised,45°dump)2877mm(113.3in)2783mm(109.6in)
J(reach-fullyraised,45°dump)1323mm(52.1in)1435mm(56.5in)
K(reach-2.13m(7.0ft),45°dump)1855mm(73.0in)1918mm(75.5in)
L(digdepth)91mm(3.6in)91mm(3.6in)
ISOLoadSpecications
OperatingWeight(withoutload)15359kg(33861lb)15313kg(33759lb)
Operatingload3847kg(8481lb)3906kg(8611lb)
Tippingload
Machinestraight
40°turn
9595kg(21152lb)
7694kg(16962lb)
9729kg(21449lb)
7812kg(17222lb)
