8-SPECIFICATIONS
LEIL16WHL0630FB38
721GXTSpecications-2.3m³(3.0yd³)Blade/2.1m³(2.8yd³)TeethwithJRBCoupler
BucketwithBolt-onEdgeBucketwithteeth
ISOBucketSpecications
Capacity(heaped)2.29m³(3.00yd³)2.14m³(2.80yd³)
Bucketwidth(maximumouter)2700mm(106.3in)2713mm(106.8in)
DimensionalOutlineSpecications
A(topofcabheight)3377mm(133.0in)3377mm(133.0in)
B(wheelbase)3253mm(128.1in)3253mm(128.1in)
C(groundclearance)384mm(15.1in)384mm(15.1in)
D(rearangleofdeparture)29°29°
Overallwidthw/obucket2558mm(100.7in)2558mm(100.7in)
Centerlinetreadwidth2030mm(79.9in)2030mm(79.9in)
Turningradius(outsideoftires)5748mm(226.3in)5748mm(226.3in)
Turninganglefromcenter40°40°
Totalturningangle
80°80°
E(fullyraisedwithspillguard)5515mm(217.1in)5515mm(217.1in)
F(hingepin-fullyraised)4156mm(163.6in)4156mm(163.6in)
G(overall-bucketlevelonground)7943mm(312.7in)8087mm(318.4in)
H(dump-fullyraised,45°dump)2918mm(114.9in)2826mm(111.3in)
J(reach-fullyraised,45°dump)1275mm(50.2in)1388mm(54.6in)
K(reach-2.13m(7.0ft),45°dump)1827mm(71.9in)1894mm(74.6in)
L(digdepth)90mm(3.5in)88mm(3.5in)
ISOLoadSpecications
OperatingWeight(withoutload)15146kg(33392lb)15100kg(33290lb)
Operatingload4011kg(8844lb)4072kg(8978lb)
Tippingload
Machinestraight
40°turn
9953kg(21942lb)
8023kg(17687lb)
10092kg(22250lb)
8145kg(17957lb)
8-47
