3-CONTROLSANDINSTRUMENTS

LEIL16WHL1290AA15

6.PresstheauxiliaryF-N-Rbuttonlocatedontheright-

handsideconsole.Theindicatorlightonthebutton

willilluminatewhenactivated.

7.Presstheparkingbrakebuttontoreleasetheparking

brake.

8.PlacetheauxiliaryF-N-Rswitch(1)ineitherFOR-

WARDorREVERSEtomovethemachine.

LEIL16WHL1125AA16

3-33
