3-CONTROLSANDINSTRUMENTS

2.AuxiliaryF-N-Rswitch

TheF-N-Rfunctionofthetransmissioncontrollevermay

bemovedtotheloadercontrolleverforoperatingef-

ciency.TheauxiliaryF-N-Rswitch(1)islocatedonthe

joystickornexttothecontrollevers.

Allthefollowingstepsarerequiredtousethistransmis-

sionshiftfunction:

1.Servicebrakepressuremustbeatoperatingpressure.

2.Thetransmissioncontrolleverontheleft-handsideof

thesteeringcolumnmustbeinNEUTRAL.

3.F-N-Rswitch(1)onthejoystickornexttothecontrol

leversmustbeinNEUTRAL.

4.Machinespeedmustbezero.

5.Enginemustberunning.

LEIL16WHL1288AB11

LEIL16WHL1331AA12

LEIL16WHL1303AA13

LEIL16WHL1302AA14

3-32
