3-CONTROLSANDINSTRUMENTS
Fourfunctionvalve-onecontrollever(joy-
stick)withtwoauxiliaryfunctions
Liftarmandbucketcontrol(1)
A.DUMP
B.ROLLBACK
A-B.AUTOMATEDBUCKETMETERING–usedtoim-
provematerialmeteringoutofthebucketataconsistent
rate.Toengageautomatedfunctionality,movethejoy-
stickrapidlybackandforthfrom“A”Dumpto“B”Rollback
position.Thebucketacceleratesmorequicklywhilethis
motionismaintainedafter4neutralpointcrossings.Reg-
ularbucketcontrolresumesassoonasthebackandforth
motionisstopped.
C.HOLD(centralposition)-Theloaderarmsandbucket
willnotmovewhenthecontrolleverisintheHOLDpo-
sition.Whenreleased,thecontrolleverwillautomatically
returntotheHOLDposition.
D.FLOAT–WhenintheFLOATposition,theloader
bucketoatsacrosstheroughground.
E.LOWER
F.RAISE
Auxiliarycontrol(2)
G.AUXILIARYFUNCTION(WITHDETENT)
H.AUXILIARYFUNCTION(WITHDETENT)
Auxiliarycontrol(3)
I.AUXILIARYFUNCTION(WITHDETENT)
J.AUXILIARYFUNCTION(WITHDETENT)
LEIL16WHL1290AA9
5148315510
NOTE:sincethedecalisappliedontheright-handside
window,thedirectionsaretobeintendedasfollows:
D,E,G,I:Forward
F ,H,J:Backward
A:Right-hand
B:Left-hand
3-31
