CONTROLS AND INSTRUMENTS
2-49
FORE-AND-AFT ADJUSTMENT OF SEAT WITH
CONSOLES
Pull bracket (5) upwards, shift seat and engage
bracket.
FOLD-BACK ARMRESTS
The armrests (7) can be folded upwards for entering
and leaving the seat.
ARMRESTS ANGLE
The angle of the slope can be changed in the lowest
position irrespective of the backrest angle, using the
integrated handwheel (8).
Adjustment range +10° up to -30°.
60
61
62
