SUPPLIES AND SERVICE CHART
4-81
FUSES LEGEND
Cab - Fuse box (A)
FA.1 5A
Power-Relay (main switch function), electronic control unit, engine stop solenoid
shrinkage coil
FA.2 5A Start-Relay, optional: Grid-Heater-Controller
FA.3 5A Free
FA.4 2A Sensors earthing
FA.5 15A Optional: Filling system
FA.6 5A
Electric-hydraulic pilot control safety switch, Relay for main unit voltage supply,
work pilot control lamp, travel pilot control lamp
FA.7 5A Box Voltage Supply - Power Control System
FA.8 5A Parking brake switch, brake lamp (lamp), alternator (energizing voltage)
FA.9 10A Optional: seat compressor, additional heating gauge
FA.10 5A Optional: stabilizers/blade
FA.11 10A Main beams
FA.12 1A Voltage supply for left and right hydraulic control levers
FA.13 2A Voltage supply - Electro-Hydraulic Controller
FA.14 30A Voltage supply - Electro-Hydraulic Controller
FA.15 1A Voltage supply for travel pedal and key-pad module on flywheel
FA.16 5A Optional: lubrication pump voltage supply
FA.17 15A Optional: Additional heating
FA.18 5A Optional: Additional heating
FA.19 7.5A Optional: blower level 1 for additional heating
FA.20 5A Optional: quick coupler
FA.21 5A Optional: heating filter relay, Grid-Heater-Controller
FA.22 30A Optional: heating filter
FA.23 25A Stop solenoid shrinkage coil
FA.24 5A Diagnostics electric socket
FA.25 10A Voltage supply for 24 V/12 V radio and socket transformer
FA.26 2A Relay for cab inner light
FA.27 2A Power-Relay (main switch operation)
FA.28 15A Ignition start lock
FA.29 5A Emergency direction indicators
FA.30 15A Blower / compressor for air conditioner
FA.31 - Free
FA.32 - Free
